JM-130LR NEW MODEL HOT & COLD CUTTING MACHINE
$4,965.00
- Description
Fully automatic cutting, simple operation, wide application range, and high cutting quality. Can be cut with a cold or hot knife.
Features:
high speed: It can cut 170 pieces per minute. (Take 50mm length as an example)
High precision: Each cut-off is monitored by a stepping motor to ensure the high accuracy of each operation.
high speed: It can cut 170 pieces per minute. (Take 50mm length as an example)
High precision: Each cut-off is monitored by a stepping motor to ensure the high accuracy of each operation.
Smooth cut surface: The hot knife can heat-seal the cut surface of colored ribbons and thin woven tapes, and the sealing is smooth and free of burrs, but the effect is not good for thick materials. The blade is made of high-quality imported steel and has a long service life.
Automatic operation: Just set the cutting length and quantity you need, and the rest of the work is done automatically.
Automatic operation: Just set the cutting length and quantity you need, and the rest of the work is done automatically.
Auto pause: Once the material is used up. It will automatically stop working.
memory function: Before the switch is turned off, the set cutting length, cutting quantity, and cutting speed are automatically stored.
memory function: Before the switch is turned off, the set cutting length, cutting quantity, and cutting speed are automatically stored.
Material can be cut
Nylon braided belts, colored ribbons, backpack belts, and other nylon materials.
|
model
|
Cutting length (mm)
|
Maximum cutting width (mm)
|
Cutting speed (p/min)
|
Maximum blade temperature (℃)
|
Voltage (v)
|
Recommended air pressure
|
Rated power (kw)
|
Packing size L×W×H (mm)
|
Weight (kg)
|
Chassis packaging size
L×W×H
(mm)
|
Weight (kg)
|
Packing rate (set)
|
|
JM-130LR
|
20-99999
|
190.5
|
170
|
350
|
110/220
|
0.3-0.6
|
0.9
|
675×645×695
|
105
|
550×445×465
|
20
|
2
|
|
JM-130LR
|
20-99999
|
279.4
|
170
|
350
|
110/220
|
0.3-0.6
|
1.5
|
675×742×695
|
120
|
655×470×470
|
22
|
2
|
